The MR-ACT remote volcanic gas monitoring system enables long-range gas detection up to a 5 km radius, performing qualitative identification and dynamic quantitative inversion of toxic, hazardous, and chemical gases. It provides real-time insights for environmental monitoring, industrial safety, and emergency response.
This system delivers:
Target Industries and Applications: Petrochemical, Fire Protection, Environmental Monitoring, Emergency Response, Chemical Manufacturing.
| Parameter | Value |
|---|---|
| Measurable gas | Petrochemical industry: methanol, ethanol, acetic acid, aniline, styrene, etc.; Fire protection industry: AC, CS2, nitric acid, hydrazine, benzene, etc.; Other chemicals: hydrazine, ASH3, H2S, NF3, HCL, SO2, etc.; Other poisonous gases: special poisonous gases. More than 400 kinds of gases can be measured. |
| Detector type | Cooled mercury cadmium telluride detector |
| Spectral range | 8~12μm |
| Spectral resolution | Better than 1cm-1 |
| Spectral acquisition rate | 20 spectra/second (Δσ≤ 1 cm-1, double-sided interference pattern) |
| Camera resolution | 640 x 512 pixels (night vision infrared) |
| Voltage/power consumption | (110~230) VAC / < 120 W |
| Installation method | Fixed, portable, vehicle-mounted |
| Dimensions | 380×270×500mm (length×width×height) |
| Weight | 28Kg |
